Products DENSO

DENSO® Petrolatum tapes and mastics

The world’s first passive corrosion protection system for pipelines. Invented by DENSO in 1927, DENSO® petrolatum tapes and mastics quickly became the standard for ideal corrosion protection.

Systems are approved by the DIN-DVGW Institute Load class A-30 (DIN 30672, DIN EN 12068)

  • Highly plastic products for modelling on complex shaped parts

  • Cold application
  • Backing: Petrolatum (technical petroleum jelly) on non-woven fabric
  • Low degree of cleaning
  • No primer required
  • Can be wound or applied in individual strips
  • The ability to model the shape
  • Can be applied to damp surfaces

DENSO® Petrolatum tapes and mastics

DENSO® PETROLATUM TAPES AND MASTICS :

Application

They are used for filling cavities and levelling uneven surfaces on pipeline structural elements (e.g. flange connections and fittings), thus providing corrosion protection.

  • Flange connections
  • Complex shaped parts
  • Fittings
  • Wet pipes

Wet pipe in pipeline operation conditions

Insulation of wet pipelines in service conditions

Causes of condensation on the pipeline:

  • The pipe is in operation
  • Large temperature difference between the product and the environment
  • High humidity

Wet pipelines in service are usually insulated as usual:

  • Pressure reduction
  • Use of tents and dehydrators
  • Special epoxy coating > disadvantage: surface finish SA 2.5. – mandatory!
  • Disconnectingthe pipeline
Traditional corrosion protection cannot be applied to wet surfaces.
It’s time-consuming, difficult, expensive.

Sandblasting is not always permitted on the pipe in service!

Problems to solve:

  • Avoid shutting down the pipeline
  • Do not use a gas burner
  • Do not sandblast
  • Do not use special equipment (heaters, tents, etc.)
  • Find a quick, simple, cost-effective solution
  • Provide long-term corrosion protection

Advantages

DENSO®-TAPES: VivaxCoat®

VivaxCoat® / Benefits:

  • Application to a wet pipe
  • Displaces water
  • No need to disconnect the pipeline
  • No high degree of cleaning required
DENSO®-AQ Primer:

Without sandblasting. Water repulsion.

DENSO®-Tape LT/MT:

Excellent corrosion protection.
High drop point. Winding in 2 layers.

DENSOLEN®-AS50:

Self-vulcanising. 3-layer PE/butyl rubber tape. Excellent mechanical protection. Winding in 2 layers.

Gasunie Germany, CS Embsen, fitting insulation

A selection of projects

Amber Grid, Lithuania
GRTGaz, France
ONTRAS Gastransport,
Germany STORENGY Cerville, France
